HENAN KONE CRANES CO.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | KN |
| Certification: | BV CE ISO |
| Model Number: | QD |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 30work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000PCS |
| Warranty Of Core Components:: | 1 Year | Core Components:: | Motor |
|---|---|---|---|
| Condition:: | New | Span:: | 5m-35m |
| Place Of Origin:: | Xinxiang, China | Brand Name:: | Crane |
| Certification:: | CE ISO | Material:: | Q235/Q345 Steel Plate |
| Highlight: | 35m Double Girder Bridge Crane,20T Double Girder Bridge Crane,DG bridge crane end trucks |
||
Top Quality 75/20T Double Girder Overhead Crane / Bridge Crane End Trucks
Use of explosion-proof double beam crane (QB)
Explosion-proof cranes are widely used in factories, warehouses, and stockyards of chemical companies. There are two forms of ground and driver’s cab. The driver’s cab is divided into two types: open and closed. The installation form is divided into left and right, and the entry direction is divided into side, End face, for users to choose according to their respective usage.
This crane is suitable for the environment of explosive gas or explosive dust, and the hook bridge crane with explosion-proof requirements. It is used for material lifting, equipment installation and maintenance.
This machine is composed of a box-shaped bridge frame, a cart operating mechanism, a cart, and electrical equipment. All mechanisms are operated in the operating room.
When used in the open air, it is equipped with rainproof equipment.
| Capacity | Main hook | ton | 5-600 |
| Aux. hook | Custom made | ||
| Span | m | 7.5~31.5 or custom made | |
| Max lifing height | Main hook | m | 30 or custom made |
| Aux. hook | |||
| Speed | Main hook lifing | m/min | 0~22 or custom made |
| Aux. hook lifing | |||
| Trolley traversing | m/min | 0~60 or custom made | |
| Crane traelling | 0~120 or custom made | ||
| Working duty | ISO | A3~A8 | |
| FEM | 1AM, 2M, 3M, 4M | ||
| Working environment temperature | ℃ | -25~40 or custom made | |
| Motor protection grade | IP54/IP55/IP65 | ||
| Crane track rail | 38kg/m,43kg/m,QU70,QU80,QU100,QU120 | ||
| Control method | Cabin/ wireless remote | ||
| Power supply | 3-phase, AC 220V~480V | ||
| Bridge crane Feature Double Girder Overhead Crane 5ton 10ton 20 ton Price | ||
| model | QD | also can make QE |
| load capacity | 10-50 tons | customized |
| span | 10-31.5 meter | customized |
| lifting height | 6-16 meter | customized |
| working class | A5-A8 | customized |
