Name: HB Wire Rope Type 5 Ton Explosion Proof Electric Hoist
Brand: KN
SKU: HB

Home Products Explosion Proof Electric Hoist

HB Wire Rope Type 5 Ton Explosion Proof Electric Hoist

Product Details:

Place of Origin:	HENAN,CHINA
Brand Name:	KN
Certification:	CE,ISO
Model Number:	HB

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Wooden box
Delivery Time:	30 work,days
Payment Terms:	L/C, T/T
Supply Ability:	1000pcs

Contact Now

Detailed Product Description

Power Supply::	380V 50Hz Three-phase	Lifting Height::	6,9,12,18,24,30,36m
Capacity::	3.2-10ton	Keywords::	Electric Wire Rope Lifting Hoist Winch
Other Name::	Wire Rope Hoist	Sling::	Steel Wire Rope
MOQ::	1	Item::	Wire Rope Hoist
High Light:	5T Explosion Proof Electric Hoist , HB Explosion Proof Electric Hoist , 36m 5 ton electric wire rope hoist

HB Model Wire rope type 5 ton explosion-proof electric hoist

HB 5 ton explosion-proof electric hoist

1. BCD (HB)Explosion-proof electric wire rope hoist is same with common CD,HC Electric hoist

2. For each of the Explosion-proof sign is ExdIIBT4,ExdIICT4

3. Working Class M3,Enviroment Temperature-20~40C

Applications :HB Series exposion proof electric hoist adapts to the environment in factory that has explosive gas formed by inflammable gas, steam and air of which explosion proof grade is less than B grade or C grase and ignition group is more than T4 group .And the explosion proof electric hoist adpats to 1 area or 2 area ,not 0 area

Features and advantages of explosion-proof electric hoist

1. Compact structure, light weight, safe and reliable

2. Components with good compatibility and high interchangeability

3. Strong lifting capacity and convenient maintenance

4. Easy to operate, accurate and stable lifting

5. The hoisting motor adopts the professional explosion-proof cone rotor brake asynchronous motor,Safe and reliable

Product parameters

Model	0.5T	1T	2T	3T	5T	10T
Lifting speed m/min	8	8	8	8	8	8
Lifting height	6/9/12	6/9/12	6/9/12	6/9/12	6/9/12	6/9/12
running speed m/min	20	20	20	20	20	20

What is the function of electric hoist?

1.HC Electronic Hoist is a small-sized lifting equipment.

2.HC Electronic Hoist has the advantages of light weight, small size, compact structure, more

varieties of different specifications, running smoothly.

3. HC Electronic Hoist can do it in the same plane as straight, curved, recycling use of aerialorbit, and can also be used in crane such as steel electric single track beam, manual single

beam, bridge, suspension, cantilever, gantry etc.

4. HC Electronic Hoist is widely used in factories, mines, harbors, terminal, ware houses and

cargo storage areas.

5. HC Electronic Hoist is essential in raising working efficiency and improving working conditions.

What parameters do you want to know?

1. Lifting Weight:16Ton~100Ton

2. Lifting Height:6m~48m

3. Power:Three-phase ac 380 v, 50 HZ

4. Lifting Speed:2m/min~6m/min

5. Running Speed:1~20m/min

6. Lifting Motor:Motor load keeping rate is 25%, Safe and reliableClass B or Class F insulation,Motor protection grade IP44 / IP54

7. Wire Rope:To adopt GB / T 20118-2006 (6 * 37 + 1) lifting wire rope, to ensure durable using.

Which size do you need?

Type	HC				HC(A2D)
Lifting weight t	16	20	25	32	36	56	100
Lifting height m	9~48	9~30	9~30	6~24	6~24	6/9/12/18	6/9/12/18
Hoisting speed m/min	3.5~6	4		3		2
Running speed m/min	20					5~20	1~20
				5~20

Steel wire rope type	6×37+1
H beam orbit model	45a-63c	45a-63c	50a-63c	50c-63c	50c- 63c


Minimum curvature radius	3.0/3.6/4.8	3.2/3.7/4.9	3.2/3.8/5	3.3/3.8/5
Power	Three-phase ac 380 v, 50 HZ
Working system	Intermediate M3
